V400 Vertical Adjustable Set Hinge 2D, Reversible, 4x4, Brass
- Regular price
- $68.71
- Regular price
-
- Sale price
- $68.71
- Unit price
- per
Vendor: Amesbury Truth Hardware
Product Type: Hardware
Sku: 363710-AB
V400 Vertical Adjustable Set Hinge 2D fits 4" x 4" (101.6mm x 101.6mm) door preps with a 5/8" (15.9mm) corner radius and is fully reversible for left or right-hand use. Allows for 1/4" (6.4mm) vertical and 3/16" (4.8mm) horizontal adjustment with a 3/32" hex wrench. Hex head adjustment screws provide secure tool engagement, and a unique shield keeps out debris for a clean look.
Couldn't load pickup availability
V400® Vertical Adjustable Set Hinge 2D – Choose Color
The V400® Vertical Adjustable Set Hinge 2D is designed for reliable vertical and horizontal adjustment of standard 4" x 4" (101.6mm x 101.6mm) doors. This set hinge is reversible and can be easily installed for either left or right-handed doors, with a removable pin for added flexibility. It seamlessly retrofits a 4" x 4" one-step pocket route door with a 5/8" (15.9mm) corner radius, making it a suitable upgrade or replacement for a variety of door materials including wood, vinyl, aluminum, and steel.
Crafted with a brass substrate for durability, the hinge features advanced Teflon-filled bushings for increased wear resistance and enhanced, low-torque adjustment. The hinge panel leaf is shielded to keep out debris, offering a premium look when the door is closed. Hex head adjustment screws help prevent stripping and secure a firm engagement during installation and future adjustments. The optimized screw hole locations minimize the risk of splitting wood at the door panel edges.
This hinge enables vertical adjustments up to 1/4" (6.4mm) and horizontal adjustments up to 3/16" (4.8mm) for precise alignment and door performance. The finish-matched bushing blends with available hardware colors for a consistent appearance. Non-removable pin (NRP) options are available for secure outswing applications. The hinge exceeds BHMA Grade 3 performance standards, ensuring quality and reliability.
Technical Information
- Hinge Size: 4" x 4" (101.6mm x 101.6mm)
- Corner Radius: 5/8" (15.9mm)
- Material: Brass substrate
- Adjustment Range: 1/4" (6.4mm) vertical, 3/16" (4.8mm) horizontal
- Suitable Door Types: Wood, vinyl, aluminum, steel
- Handed: No – Reversible for left or right
- Pin: Removable; NRP option available
- Adjustment Mechanism: 3/32" (2.4mm) hex wrench
- Meets/Exceeds: BHMA Grade 3
- Installation Screws (not included):
– 3: #9 x 1" (25.4mm) flat head wood screws for jamb wing
– 1: #9 x 3" (76.2mm) flat head wood screw for jamb wing
– 4: #9 x 1.5" (38.1mm) flat head wood screws for panel wing
Notes
- Standard 3 hinge door uses 2 Guide Hinges and 1 Set Hinge.
- Available in Brushed/Satin Nickel, Polished Brass, Antique Brass, Polished Chrome, White, Brushed/Satin Chrome, Oil Rubbed Bronze, and Antique Nickel/Pewter (limited supply – slightly darker than satin nickel).
- Installation screws are not included and must be sourced separately.
- Antique Nickel/Pewter finish is limited to existing inventory.
Please confirm measurements of your existing hardware carefully to ensure proper fit before ordering. Accurate measurements are essential for correct installation and reducing returns.
