2-1/8" L-Shaped T-Head Pivot Bar, 2-Hole Zinc Die Cast

PIVOT BAR, 2-1/8" L-Shaped T-Head, 2-Hole – Zinc Die Cast

This L-Shaped T-Head pivot bar is designed for use in tilt windows that require secure pivoting action for tilt-in operation. With an overall length of 2-1/8" (54.0mm), this replacement part offers a sturdy solution for worn or damaged pivot bars, restoring smooth sash functionality. Its two-hole configuration provides reliable attachments, and it is constructed from durable zinc die cast material for long-term resistance to wear and corrosion.

The pivot bar features precise hole placements: the first hole is 1-3/16" (30.2mm) from the T-head, while the second is 1-7/8" (47.6mm) from the T-head, with 11/16" (17.5mm) spacing between holes. Measuring 21/64" (8.3mm) wide and 1/8" (3.2mm) thick, it is engineered for compatibility with many contemporary and legacy tilt window systems, including units commonly fitted with Amesbury Truth Hardware components. The end design ensures stable sash-to-frame engagement during operation.

Technical Information

• Pivot Type: L-Shaped, T-Head
• Overall Length: 2-1/8" (54.0mm)
• Width: 21/64" (8.3mm)
• Thickness: 1/8" (3.2mm)
• 1st Hole from T-Head: 1-3/16" (30.2mm)
• 2nd Hole from T-Head: 1-7/8" (47.6mm)
• Hole Spacing: 11/16" (17.5mm)
• Material: Zinc die cast
• Vendor: Amesbury Truth Hardware

This pivot bar is sold individually. Please verify all dimensions and compare with your current hardware to ensure a proper fit before ordering. Always double-check measurements of your existing hardware for best results.
