Left Hand Inactive Patio Door Handle Set, 100 Series C Plate

Inactive Handle Set – 100 Series Lever, C Plate, Left Hand

This inactive, non-keyed lever handle set is designed as replacement hardware for select patio doors, including models from Marvin®, Milgard®, and other leading brands. Built for 100 Series door systems with a Regency profile, it features an arched 'C' style escutcheon plate for a clean, classic appearance.

Constructed from durable zinc for longevity, this handle set is also available in a premium brass substrate with a PVD (Physical Vapor Deposition) finish. The PVD option is specifically engineered for coastal or high-humidity areas to resist tarnishing and discoloration, providing lasting visual appeal.

This unit is left-handed, but handing can be changed thanks to the lever's C-ring (circlip) mounting. Intended for inactive side applications, this set does not include a locking cylinder, keyway, or thumb turn. Instead, it provides a matching look and functional grip as the non-locking trim for multi-point or other patio door configurations that require inactive hardware.

Technical Information

• Plate Style: "C" Style, slight arch
• Material: Zinc (also available in Brass substrate PVD finish)
• Handing: Left Handed (reversible by changing lever orientation)
• Actual Plate Width: 1.79" (45.5mm)
• Overall Plate Height: 9.47" (240.5mm)
• Escutcheon Plate Screw Hole Spacing: 7.87" (199.9mm)
• Handle Projection: 2.31" (58.6mm)
• Handle Clearance: 1.34" (34mm)
• Handle Length: 4.58" (116.3mm)
• Handle to Cylinder (from base of handle to where cylinder would be): 3.62" (92mm)
• Cylinder Type: None (non-keyed)

Notes

• Replacement hardware, compatible with Marvin® and Milgard® door systems.
• Ideal for inactive panel applications where no lock or key function is required.
• PVD finish recommended for coastal or humid environments.

Each set includes one handle and matching escutcheon plate; levers are secured with a C-ring for ease of handing adjustment. Always measure your existing hardware carefully to ensure the correct fit before ordering. Double-check dimensions and door handing for best results.
