Weather Shield #17 Heavy Duty 1/2" Ribbed Channel Balance for Vinyl Jambliners

1/2" Ribbed Channel Balance for Vinyl Jambliners, Heavy Duty, Weather Shield #17 End Bracket

This heavy duty 1/2" ribbed channel balance is designed specifically for wood double hung tilt-in windows equipped with vinyl jambliners made by Weather Shield, used primarily in premium wood and clad windows produced from 1999 to 2005. The unit features a factory-attached #17 end bracket, color coded in black to indicate its heavy-duty capacity. This balance is not suitable for use in all-vinyl windows, but is engineered for wood windows with vinyl-lined jambs, matching the original specifications for these Weather Shield products.

The channel balances were available in both beige and white finishes to coordinate with jambliners, and bracket color codes help you identify the correct duty strength for your window. This listing specifically covers heavy duty units (black end bracket), which are used in applications requiring extra support for larger or heavier sashes.

If your required size is no longer available in our existing inventory, an alternative part can be found at 620202. Replacement balances are designed to work with most Weather Shield pivot pins, which are available here: left hand cam pivot pin (640015) and right hand cam pivot pin (640016).

Technical Information

• Fits: Premium Weather Shield wood and clad windows (1999-2005) with vinyl jambliners
• Channel Balance Width: 9/16" (14.3 mm)
• Channel Balance Depth: 5/8" (15.9 mm)
• Channel Balance Length: Varies, from 10" up to 52" (254.0 mm to 1,320.8 mm)
• Color: Beige or White to match vinyl jambliner
• End Bracket: #17 (Heavy Duty, Black color code)
• Application: Wood double hung, tilt-in windows only

Notes

• Limited to existing inventory.
• Due to age (from 2005) and standard shipping, some minor surface scratches may be present.
• Not for use with all-vinyl windows.
• Other bracket color codes: White (Regular Duty), Blue (Triple Duty), Green (Extra Heavy Duty), Red (Super Duty)

Replaces / Replaced by

• If unavailable, see part 620202 for suitable replacement.

Please ensure you measure your existing channel balance length, width, and depth accurately and match the end bracket color code before ordering to ensure a correct fit. When in doubt, always measure existing hardware before purchasing replacements.
